LED BULKHEAD ECO SERIE IP54
B74325-Oval/8W·12W·15W·18W·20W
PC cover + PC base
Beam Angle 120°
High efficiency constant current driver
With the advantage of energy conservation
Ideal for building, elevated bridge, garden, courtyard and bathroom use
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
|
POWER |
VOLT |
LUMENS |
EEL |
ANGLE |
PF |
RA |
CCT |
DIM |
IP |
Class Ⅱ |
LxWxH |
LIFE |
| 8W | 120V/230V | 640Lm | A+ | 120° | 0.5 | >80 | 3000K/4000K/6500K | NON-DIM | IP54 | II | 160x90x46mm | 25,000H |
| 12W | 120V/230V | 960Lm | A+ | 120° | 0.5 | >80 | 3000K/4000K/6500K | NON-DIM | IP54 | II | 198x98x46mm | 25,000H |
| 15W | 120V/230V | 1200Lm | A+ | 120° | 0.5 | >80 | 3000K/4000K/6500K | NON-DIM | IP54 | II | 230x103x46mm | 25,000H |
| 18W | 120V/230V | 1440Lm | A+ | 120° | 0.5 | >80 | 3000K/4000K/6500K | NON-DIM | IP54 | II | 230x103x46mm | 25,000H |
| 20W | 120V/230V | 1600Lm | A+ | 120° | 0.5 | >80 | 3000K/4000K/6500K | NON-DIM | IP54 | II | 230x103x46mm | 25,000H |
